Sett Surface

Reply within one working day. Layouts and calculations included when we supply.

Description
Specification

The backstage hero

Sett Surface offers a contemporary alternative to downlights in exposed ceilings. Proportionately designed with visible heat sink and screws blending in, the Sett has a strong industrial look and feel. Used in corridors, hallways and circulation areas, this surface mounted downlight is a bold design solution for projects with no ceiling voids or restricted access.

Available in 3 different outputs, the Sett is suitable for most commercial applications, from lower or standard ceilings to double or triple-height atrium spaces.

The Sett Surface mounted is available in 3 standard colours or 'stand out from the crowd' and choose any RAL colour to match your design scheme. Sett is ideal for all those important backroom parts of your scheme or hard working environments like airports, where reliability is the key.

Simple installation is an advantage when on site and Sett offers just that. 

The SETT can be specified with both CASAMBI and Philips EasyAir to increase user control.

Light Source Information

· Surface Mounted
· Output: 12W - 1100Lm / 20W - 2000Lm / 31W - 3200Lm
· 50,000hrs, L80 B20
· LED Efficiency of 97 lm/W
· Colour Temperature 3000K / 4000K
· 3 MacAdam

Design
· Diameter Ø170
· Standard Body Finish White, Black and Grey
· Made from steel and aluminium
· IP20 in standard, IP44 on request

Optics
· Clear or frosted glass on request

Dimming
· DALI DIM are available on request

Controls (on request)

· Casambi
· Philips EasyAir

Installation

· Installation Instruction available on request

Miscellaneous
· 3H Emergency available on request
· 2 years warranty

Downloads.

Download datasheet

Download LDT files

Download Installation Instructions

Download 3D files

TM65 report (on request)

Need a TM65 embodied-carbon report or BIM objects? Ask us and we will send them for your project.

Questions about Sett Surface.

What is the efficacy of Sett Surface?

Sett Surface delivers up to 97 lm/W, depending on the output, optic and configuration chosen. The figure for your exact configuration is on the datasheet and your quotation.

How does Part L apply to Sett Surface?

Part L compliance is judged on the luminaire lumens per circuit-watt average that Approved Document L sets for general lighting across the whole installation, so one product's headline efficacy does not settle compliance. We check the average for your whole scheme when we prepare the layout.

Can Sett Surface be dimmed?

Yes. Sett Surface is available with DALI or Casambi control. Tell us how the space will be used and we will recommend the right driver and controls.

How do I get a quote or sample for Sett Surface?

Use the Request a quote or Request a sample button on this page, or send your drawings to info@299lighting.co.uk. A Light Engineer replies within one working day, and we can include a lighting layout and calculations.

Product Configurator

Select your configuration options below

Products Available: 1000 | Matching: 1000

Main Configuration

Versatility

To give the user more freedom, Sett can be specified as Dali dimmable. It also offers emergency integration and is available with an IP44 rating (on request).

For some applications, movement detection is vital in order to save on energy consumption and keep the operating cost down. Sett can be equipped with a microwave sensor.

Industrial look

Industrial, yet contemporary, the SETT offers a bold design option to all the important backroom areas in the workplace.

Sett is also available as a suspended mounted option, which is a perfect lighting solution for areas with standard ceilings to double or triple-height atrium spaces.

Wireless Control

All mounting styles of Sett can be easily upgraded with Casambi or Philips EasyAir controls, allowing faster and easier installation and commissioning. Putting the user in charge, wireless controls are a serious proposition for workplace future-proofing with increased energy saving and wellbeing.
